GL300WDataCable

(Optionalaccessory)



It is the USB data cable which

can be used for firmware

upgradingandconfiguration.

GL300WExternalCable

(Optionalaccessory)



It is the extend cable which

include the charger interface

and external battery interface

onGL300W.Italsoincludesthe

ignition detection interface on

theGL300W.

3.2. Battery Charging

 PleaseconnectAC‐DCpoweradapterwithGL300W.

 InserttheAC‐DCpoweradapterintothepowersocket.

 Duringcharging,thePWRLEDisflashingfast.Whenthebatteryisfullcharged,thePWRLED

willbeEver‐light.

 YoucanalsochargethebatterybyUSB

cablewhichconnectsGL300WwiththePC.

 Chargingtimeisabout5hours.

Note:BeforethefirsttimeusingGL300W,pleasefullchargethebattery.

3.3. GL300W External Cable Interface

 GL300WExternalCableisacablewithaMiniUSBconnectorandsixwireswhichinclude

the external power interface, ignition detect and input interface for GL300W. Please

findthedetaildescriptioninfollowingtable.



Color Name Remark

RED ExternalDCIN(5V) Pleasereferto2.4.1fordetail

Black Ground Pleasereferto2.4.1fordetail

Blue ExternalBatteryIN(DC3.4Vto4.2V) Pleasereferto2.4.2fordetail
