3.2. Module TE-A Interface
Module TE-A interface is designed to accommodate the TE-A of applicable modules. The TE-A is
connected to the EVB via BTB connectors. The developer will be able to test the functionalities of the
module easily (insert as indicated by the arrow to prevent reverse insertion).
Table 4: Description of Module TE-A Interface
The following figure shows the connection between the module TE-A and the EVB.
Figure 8: Connection Between the Module TE-A and EVB
