3.10. Antenna Interfaces
The EVB includes six antenna interfaces:
Table 17: Description of Antenna Interfaces
The following figure shows the assembly of these antenna interfaces.
Figure 26: Antenna Interfaces
J1617
J1623 J1619
J1624 J1620
J1604
RefDes.
Description
J1604
Antenna connectors
J1617
J1619
J1620
J1623
J1624
