Quectel BG95 A-GL Series - Page 13

LPWA Module Series
BG95xA-GL&BG950S-GL_TE-B_User_Guide 12 / 24
U0301
C0223
U0201
C0227
C0231
U0304
U0306
U0305
U0303
U0302
Figure 4: Bottom Components & Interfaces Placement
Table 1: Components & Interfaces Information
Components/Interfaces
RefDes
Description
BG95xA-GL/ BG950S-GL
U0101
BG95xA-GL & BG950S-GL module
DC-DC
U0201
DC-DC converter
LDO
U0202
3.3 V low dropout voltage linear regulator
U0203
1.8 V low dropout voltage linear regulator
USB-to-UART Bridge
U0301
USB to UART bridge controller
Voltage-level Translators
U0302, U0303,
U0304, U0305,
U0306
Bidirectional voltage-level translator
