LPWA Module Series

BG95xA-GL&BG950S-GL_TE-B_User_Guide 23 / 24

4. Turn on the output voltage set by N6705C, and turn on the module after power up.

5. Conduct current consumption tests in different operation modes.

S0201

J0202

Micro USB cable

RF antenna

GNSS antenna

Figure 11: Wiring Diagram
