Quectel BG95 Series

LPWA Module Series
BG95 Hardware Design
BG95_Hardware_Design 13 / 80
2 Product Concept
2.1. General Description
BG95 is a series of embedded IoT (LTE Cat M1, LTE Cat NB2 and EGPRS) wireless communication
module. It provides data connectivity on LTE-FDD/GPRS/EGPRS networks, and supports half-duplex
operation in LTE networks. It also provides GNSS
1)
and voice
2)
functionality to meet customers’ specific
application demands.
Table 1: Version Selection for BG95 Series Module
Table 2: Frequency Bands and GNSS Types of BG95 Series Module
Version Cat M1 VoLTE
Cat NB2
3)
/
NB1
GSM
Wi-Fi
Positioning
GNSS
(Optional)
BG95-M1
Y Y N N N Y
BG95-M2*
Y Y Y N N Y
BG95-M3*
Y Y Y Y N Y
BG95-N1*
N N Y N N Y
BG95-M4
4)
Y Y Y N N Y
BG95-M5
4)
Y Y Y N N Y
BG95-MF
4)
Y Y Y N Y Y
Module Supported Bands LTE Bands Power Class GNSS (Optional)
BG95-M1
Cat M1 Only:
LTE-FDD:
B1/B2/B3/B4/B5/B8/B12/B13/
B14/B18/B19/B20/B25/B26*/B27/
B28/B66/B85
Power Class 5 (20dBm)
GPS,
GLONASS, BeiDou,
Galileo
