6.6. Electrostatic Discharge
The module is not protected against electrostatics discharge (ESD) in general. Consequently, it is subject
to ESD handling precautions that typically apply to ESD sensitive components. Proper ESD handling and
packaging procedures must be applied throughout the processing, handling and operation of any
application that incorporates the module.
The following table shows the electrostatic discharge characteristics of BG95 module.
LTE-FDD B13 TBD /-99.3 TBD/-107.5
LTE-FDD B14 TBD /-99.3 /
LTE-FDD B18 TBD /-102.3 TBD/-107.5
LTE-FDD B19 TBD /-102.3 TBD/-107.5
LTE-FDD B20 TBD /-99.8 TBD/-107.5
LTE-FDD B25 TBD /-100.3 TBD/-107.5
LTE-FDD B26* TBD /-100.3 TBD/-107.5
LTE-FDD B27 TBD /-100.8 /
LTE-FDD B28 TBD /-100.8 TBD/-107.5
LTE-FDD B66 TBD TBD/-107.5
LTE-FDD B71 / TBD/-107.5
LTE-FDD B85 TBD TBD/-107.5
Network Band Primary Diversity
Sensitivity (dBm)
GSM/3GPP
GSM
GSM850/EGSM900
Supported
Not
Supported
TBD/-102
DCS1800/PCS1900 TBD/-102
