Quectel BG95 Series

LPWA Module Series
BG95 Hardware Design
BG95_Hardware_Design 26 / 80
Pin Name Pin No. I/O Description DC Characteristics Comment
DBG_RXD 22 DI Receive data
V
IL
min=-0.3V
V
IL
max=0.6V
V
IH
min=1.2V
V
IH
max=2.0V
1.8V power domain.
If unused, keep this
pin open.
DBG_TXD 23 DO Transmit data
V
OL
max=0.45V
V
OH
min=1.35V
1.8V power domain.
If unused, keep this
pin open.
GNSS UART Interface
Pin Name Pin No. I/O Description DC Characteristics Comment
GNSS_UART_
TXD
27 DO Transmit data
V
OL
max=0.45V
V
OH
min=1.35V
1.8V power domain.
If unused, keep this
pin open.
GNSS_UART_
RXD
28 DI Receive data
V
IL
min=-0.3V
V
IL
max=0.6V
V
IH
min=1.2V
V
IH
max=2.0V
1.8V power domain.
If unused, keep this
pin open.
PCM Interface*
Pin Name Pin No. I/O Description DC Characteristics Comment
PCM_CLK* 4 DO
PCM clock
output
V
OL
max=0.45V
V
OH
min=1.35V
1.8V power domain.
If unused, keep this
pin open.
PCM_SYNC* 5 DO
PCM frame
synchronization
output
V
OL
max=0.45V
V
OH
min=1.35V
1.8V power domain.
If unused, keep this
pin open.
PCM_IN* 6 DI PCM data input
V
IL
min=-0.3V
V
IL
max=0.6V
V
IH
min=1.2V
V
IH
max=2.0V
1.8V power domain.
If unused, keep this
pin open.
PCM_OUT* 7 DO
PCM data
output
V
OL
max=0.45V
V
OH
min=1.35V
1.8V power domain.
If unused, keep this
pin open.
I2C Interface*
Pin Name Pin No. I/O Description DC Characteristics Comment
I2C_SCL* 40 OD
I2C serial clock.
Used for
external codec.
External pull-up
resistor is required.
1.8V only.
If unused, keep this
