Quectel EC200U Series User Manual

LTE Standard Module Series
EC200U_Series_Hardware_Design 72 / 94
LTE-FDD B8 @ 23.1 dBm
545.5
mA
LTE-TDD B34 @ 23.01 dBm
287.1
mA
LTE-TDD B38 @ 23.1 dBm
343.9
mA
LTE-TDD B39 @ 22.95 dBm
294.6
mA
LTE-TDD B40 @ 23.12 dBm
306.4
mA
LTE-TDD B41 @ 23.37 dBm
393.3
mA
GSM voice call
EGSM900 PCL = 5 @ 33.27 dBm
250
mA
EGSM900 PCL = 12 @ 19.42 dBm
92.2
mA
EGSM900 PCL = 19 @ 6.21 dBm
62.8
mA
DCS1800 PCL = 0 @ 30.24 dBm
175
mA
DCS1800 PCL = 7 @ 16.2 dBm
75.4
mA
DCS1800 PCL = 15 @ 0.87 dBm
57.7
mA
Table 44: EC200U-EU Current Consumption
The GSM network access technology of EC200U-CN is optional. If the module that you select doesn’t
support GSM network access technology, there is no corresponding current consumption.
Description
Conditions
Typ.
Unit
OFF state
Power down
40
μA
Sleep state
AT+CFUN = 0 (USB disconnected)
1.139
mA
GSM850 @ DRX = 2 (USB disconnected)
2.078
mA
GSM850 @ DRX = 5 (USB disconnected)
1.555
mA
GSM850 @ DRX = 5 (USB suspend)
2.739
mA
GSM850 @ DRX = 9 (USB disconnected)
1.392
mA
DCS1800 @ DRX = 2 (USB disconnected)
2.085
mA
NOTE

Quectel EC200U Series Specifications

General

Brand	Quectel
Model	EC200U Series
Category	Control Unit
Language	English
