Quectel EC200U Series User Manual

LTE Standard Module Series
EC200U_Series_Hardware_Design 78 / 94
5.5. Tx Power
The following table shows the RF output power of EC200U series module.
Table 46: EC200U-CN RF Output Power
Frequency Bands
Max. RF Output Power
Min. RF Output Power
EGSM900
33 dBm ±2 dB
5 dBm ±5 dB
DCS1800
30 dBm ±2 dB
0 dBm ±5 dB
LTE-FDD B1/B3/B5/B8
23 dBm ±2 dB
< -39 dBm
LTE-TDD B34/B38/B39/B40/B41
23 dBm ±2 dB
< -39 dBm
Table 47: EC200U-EU RF Output Power
Frequency Bands
Max. RF Output Power
Min. RF Output Power
GSM850
33 dBm ±2 dB
5 dBm ±5 dB
EGSM900
33 dBm ±2 dB
5 dBm ±5 dB
DCS1800
30 dBm ±2 dB
0 dBm ±5 dB
PCS1900
30 dBm ±2 dB
0 dBm ±5 dB
LTE-FDD
B1/B3/B5/B7/B8/B20/B28
23 dBm ±2 dB
< -39 dBm
LTE-TDD B38/B40/B41
23 dBm ±2 dB
< -39 dBm
Table 48: EC200U-AU RF Output Power
Frequency Bands
Max. RF Output Power
Min. RF Output Power
GSM850
33 dBm ±2 dB
5 dBm ±5 dB
The GSM network access technology of EC200U-CN is optional. If the module that you select doesn’t
support GSM network access technology, there is no corresponding RF output power.
NOTE
