Quectel EC21 Series User Manual

LTE Standard Module Series
EC21_Series_Hardware_Design
69
/ 118
4
RF Specifications
EC21 series antenna interfaces include a main antenna interface, an Rx-diversity antenna interface
which is used to resist the fall of signals caused by high-speed movement and multipath effect, and a
GNSS antenna interface. The impedance of antenna ports is 50 Ω.
4.1. Cellular Network
4.1.1. Antenna Interfaces & Frequency Bands
The pin definition of main antenna and Rx-diversity antenna interfaces is shown below.
Table 25: Pin Definition of RF Antennas
Pin Name Pin No. I/O Description Comment
ANT_MAIN 49 AIO Main antenna interface 50 Ω impedance
ANT_DIV
35 AI
Diversity antenna interface
50 Ω impedance.
If unused, keep it open.
4.1.2. Operating Frequency
Table 26: Module Operating Frequencies
3GPP Band Transmit Receive Unit
GSM850 824–849 869–894 MHz
EGSM900 880–915 925–960 MHz
DCS1800 1710–1785 1805–1880 MHz
PCS1900 1850–1910 1930–1990 MHz
WCDMA B1 1920–1980 2110–2170 MHz
