Quectel L86

GNSS Module Series
GNSS SDK Commands Manual
GNSS_SDK_Commands_Manual Confidential / Released 25 / 28
Parameter
Example
$PQGBS,W,1,1*2C //Enable GBS sentence output and saved into flash
$PQGBS,W,OK*04 //Set OK
$PQGBS,R*29 //Read mode
$PQGBS,R,1*34 //Read OK, GBS sentence output is enabled
The command will be effective immediately after setting.
If there is any error, response:
$PQGBS,W,ERROR*ChkSum<CR><LF>
Read Command
$PQGBS,R*ChkSum<CR><LF>
Response
$PQGBS,R,<mode>*ChkSum<CR><LF>
URC Message
$--GBS,hhmmss.ss,x.x,x.x,x.x,xx,x.x,x.x,x.x*hh<CR><LF
>
Parameter definition is available in Table 5.
Example
$GNGBS,035459.000,8.30,4.43,9.41,22,0.0,-162.6,29.2,1,0*
6D
Reference
<mode> Module operation mode
0 Disable GBS sentence output
1 Enable GBS sentence output
<save> Save operation
0 Parameter is not saved, and ineffective after restart
1 Parameter is saved in flash, and effective after restart
NOTE
