29
CHC1103 IT EN FR - REV001A
EN
CHAIN COUNTER OPERATION
Lowering the anchor
To lower the anchor press key
q
(DOWN).
Hold the key pressed until the anchor reaches the desired position and then release it.
It is also possible to lower the anchor with an other electric control.
The chain counter will measure the length of the chain lowered in any case.
Getting the anchor
To get the anchor aweigh press key
p
(UP).
Hold the key pressed until the anchor reaches the desired position and then release it.
It is also possible to get the anchor aweigh with an other electric control.
The chain counter will measure the length of the chain lowered in any case.
WINDLASS ELECTRIC DRIVE
The automatic lowering procedure can be interrupted by pressing any key of the chain counter
from which the procedure was activated, by activating the up function from an external device
(from another chain counter or other control) or by shutting off the chain counter.
Automatic down function
This function can be used only if it was previously set and activated on the FUNCTIONS\AUTO
DOWN menu (see chapter SETTING THE CHAIN COUNTER).
ATTENTION: regular operation of the windlass has to be checked when moving down
automatically
To lower the anchor automatically to the set depth, press keys
=
(SELECT) and
q
(DOWN)
simultaneously for more then three seconds. Once the procedure has started, both keys can be
released. The chain counter will lower the anchor to the set depth.
CHAIN DOWN
35.3
M
SPEED
20M/M
CHAIN UP
35.3
M
SPEED
20M/M
VELOCITA' 20 M/M
AUTO DOWN
35.3
M
SPEED
20M/M
At times the anchor may have to be lowered by exploiting the possibility of the windlass to
allow for free fall (without electrical command).
The chain counter will measure the length of the chain lowered under these circumstances as
well.
FREE FALL
FREE FALL
35.3
M
SPEED
20M/M
