31
CHC1103 IT EN FR - REV001A
EN
Use keys pand
p
and
q
(UP and DOWN) to select the data items within the menu.
The data item that has been currently selected appears in reverse.
Use key
=
(SELECT) to confirm the selected data item.
SETTING THE CHAIN COUNTER
The chain counter has a several functions that can be personalized to satisfy user’s requirements.
To go to the setting menu, press and hold key
=
SELECT) for more than 3 seconds.
As soon as the key is released a window similar to the one shown below is displayed:
SETTINGS
COUNTER RESET
FUNCTIONS
PERSONAL SET
LANGUAGE
CALIBRATION
The following data items are provided on the settings menu, with the MASTER chain counter present on the network:
THE STRUCTURE
OF THE MENUS:
COUNTER RESET
FUNCTIONS
PERSONAL SET
LANGUAGE
CALIBRATION
AUTO CALIBRATE
UTILITY
CAN CONFIG
EXIT
UP ALARM
AUTO DOWN
CONTRAST
LIGHT
LIGHT DELAY
KEY BEEP
ENGLISH
ITALIANO
FRANCAIS
DEUTSCH
ESPANOL
SET MEASURE
GYPSY LAP
MAGNETS NUMBER
SENSOR TEST
LCD TEST
DEVICE INFO
SET DEFAULT
CHECK FLASH
CHECK EEPROM
CAN MESSAGE
LOCKED KEYS
FREE FALL
DATA ITEM SYNTHETIC DESCRIPTION
COUNTER RESET
Reset the measure of chain lowered.
FUNCTIONS
Automatic down and up alarm setting.
PERSONAL SET
Chain counter personalization: contrast, back-lighting, light delay, key beep,
timed locking of the p and q (UP and DOWN) keys.
LANGUAGE
System date and time setting.
CALIBRATION
Chain counter calibration: setting of the measurement unit, development of the chain on the gypsy,
the number of magnets installed, and management of the windlass with free fall.
AUTO CALIBRATE
Automatic chain counter calibration.
UTILITY
Various chain counter controls.
CAN CONFIG
MASTER/SLAVE selection in the case of multiple instruments and CAN bus speed setting.
EXIT
Chain counter set-up menu exit.
CAN PRIORITY
CAN BIT RATE
SETTING THE CHAIN COUNTER
