35
CHC1103 IT EN FR - REV001A
EN
SETTINGS MENU - AUTOMATIC CALIBRATION
Use this option to automatically calibrate the chain counter.
The first window regarding AUTOMATIC CALIBRATION is shown below:
AUTO CALIBRATE
EXIT
SET VALUE:
METERS FEET
Use this option to select the unit of measurement used to measure the chain lowered. Se-
lectable values: METERS or FEET.
Once key
q
(DOWN) is released the chain counter will stop the chain from moving down and automatically set the fol-
lowing values:
AUTO CALIBRATE
TO EXIT
UNTIL 6M
DEPTH
PRESS
PRESS
AUTO CALIBRATE
TO EXIT
UNTIL 20FT
DEPTH
PRESS
PRESS
This window tells the user the chain has to be lowered 6 meters (or 20 feet, depending on the
unit of measurement selected) in an uninterrupted manner. The length of the chain unwound
each lap can be calculated according to the number of laps completed by the gypsy (counted
by the chain counter).
GYPSY LAP
cm=600/number of laps counted
NUMBER OF MAGNETS=1
GYPSY LAP
inc=240/number of laps counted
NUMBER OF MAGNETS=1
After which the following window will be displayed for two seconds:
and the SETTINGS menu will be shown again.
AUTO CALIBRATE
END OF
PROCEDURE
SETTINGS MENU - UTILITY
This option allows the user to perform procedures to check and control the chain counter
operation.
The UTILITY Sub-menu
UTILITY
SET DEFAULT
CHECK FLASH
CHECK EEPROM
CAN MESSAGE
EXIT
UTILITY
SENSOR TEST
LCD TEST
DEVICE INFO
SET DEFAULT
CHECK FLASH
SETTINGS MENU - UTILITY - SENSOR TEST
This function can be used during installation or to check that the lap sensor works properly.
If the sensor detects the magnet, ON is displayed and the buzzer sounds; otherwise OFF is
displayed and the buzzer does not sound.
SENSOR TEST
SENSOR STATUS:
OFF
SENSOR TEST
SENSOR STATUS:
ON
SETTINGS MENU - UTILITY - LCD TEST
This function can be used to check correct operation of the LCD display’s pixels.
Once the data item has been confirmed from the utility menu, all the display pixels will be activated for 5 seconds; after
which the system will go back to menu UTILITY.
SETTING THE CHAIN COUNTER
