11
EN
INSTALLATION AND USE MANUAL QUICK MC² X19 REV002A
2 - Supplied parts
MC
2
Quick gyro stabilizer is equipped with all the parts needed for its installation.
2.0 - Package contains the following parts
1 Pre-wired MC
2
X19 Gyro stabilizer
1 Power cable (6 m long)
1 AC DYNAMIC CONTROL MC
2
Driver to control and operate the gyro
1 J1 Extention CAN BUS (6 m long)
1 J2 Extention CAN BUS (6 m long)
1 J5 Extention CAN BUS (6 m long)
4 Eye bolts for MC
2
X19 stabilizer lifting
1 Template to install the MC
2
X19 stabilizer
Screws with resistance category higher than 10.9 (Grade 8). Tightening torque 136 Nm (1203.7 lbf/inch) - M12
1 Template to install the AC DYNAMIC CONTROL MC
2
driver
INSTALLATION AND USE MANUAL
The warranty
2.1 - Needed accessory and material included in its packaging
Not supplied with the stabilizer
• RC Remote Control MC
2
touch 5", IP66 - It allows you to turn the stabilizer on and off
and monitor its status ( also in multi-station).
Supplied with:
- template for mounting the Remote Control
- J3 RC Extention CAN BUS for the CAN BUS connection to the RC Remote Control MC
2
- CAN 5P T F/F/F connector
- CAN Terminator.
2.2 - Required components, not supplied with the stabilizer
• Differential circuit breaker for connecting the AC DYNAMIC CONTROL driver.
2.3 - Tools needed for installation
• Lifting straps
• Torque wrench
• Drill & drill bit 11 mm (7/16")
• Fork key 17 mm (21/32")
• Hexagonal key 8 mm (5/16")
