INSTALLATION AND USE MANUAL QUICK MC² X19 REV002A
1 - Information about the product
1.0 - Description
The MC
2
series is the result of careful research, aimed at achieving highly competitive performances.
The Quick
®
research and development laboratories have revolutionized the MC
2
series’ concept of operation, by introducing
technical solutions capable of guaranteeing greater safety, more comfort and much higher performances.
The MC
2
series stabilizers are compact and functional.
Quick MC²X19 is useful and effective to improve comfort on board, but it does not eliminate the risks deriving
from harsh atmospheric conditions.
1.1 - Main features
• Maximum performance
• Maximum protection
• Smart and compact design
• High installation exibility
• Dynamic precession control
• Precession lock function from remote panel.
• Equipped with Quick
®
electric motors.
• Low noise emission.
• Overheating protection.
• Thermal protection.
• MC
2
Mobile App to record stabilizer performance (iOS and Andorid)
• Reduced maintenance
1.2 - Technical data
(1) Rated speed: flywheel speed (RPM: Revolutions per minute).
(2) Angular momentum: it quantifies the torque that is necessary to balance the system in the time unit (Newtons meter second).
(3) Output torque: torque generated by the rotor at rated speed (Newtons per meter).
MODEL MC2 X19 MC2 X19 LV
Rated speed (1) 5300 RPM 5300 RPM
Angular momentum (2) 6090 N·m·s 6090 N·m·s
Output torque (3) 18700 N·m 18700 N·m
Spool-up time to rated RPM 43 min 43 min
Spool-up time to stabilization 35 min 35 min
Power absorbed 3500 W max 3500 W max
AC Input voltage 200-240 Vac 90-120 Vac
Frequency 50-60 Hz 50-60 Hz
Noise output < 70 dB < 70 dB
Ambient air temperature
from -10°C to +55°C
(14° F - 131° F)
from -10°C to +55°C
(14° F - 131° F)
Weight 553 kg (1219 lb) 553 kg (1219 lb)
