INSTALLATION AND USE MANUAL QUICK MC² X19 REV002A
7 - Installation procedures
7.7 - BRACHET - EXAMPLE 4
2 - Example of support structure on a hull with insufficient space in between the longitudinal stringers.
BOAT STRUCTURE
SUPPORT STRUCTURE
