INSTALLATION AND USE MANUAL QUICK MC² X19 REV002A
8 - Electrical connection
RC remote control MC2*
147 (5
25
/32)
107 (4
7
/32
)
8 (
5
/16
)
5”
=
64 (2
33
/64
)
136 x 96 (5
23
/64 x 3
25
/32)
Dimensions in mm (inch)* Not supplied.
AC DYNAMIC CONTROL MC
2
- Driver
100 mm (4 in.)
space on each side
152 (5
63
/ 64 )
85 (3
11
/ 32 )
170 (6
11
/ 16 )
269 (10
19
/ 32 )
281 (11
1
/ 16 ) 165 (6
1
/ 2 )
585 (23
1
/
32
)
555 (21
27
/
32
)
8.1 - Devices dimensions
