930756 Rev. A
F. MOTOR LOCKS
Disconnect the motor locks when you need to manually push the chair.
(For example, in an emergency, or if batteries fail).
1.
Do not disengage motor locks unless power to the chair is off.
2. With either one or both brakes released, the chair will not operate and the
battery charge indicator will flash 9 bars rapidly (if power to the chair is on.)
3.
Be aware that the chair will not have brakes in the free-wheel position.
4. Make sure that the person pushing the chair has full control when motor
locks are disengaged.
1.
Release Motor Locks
a. At the back of the chair you will find two levers marked in red.
b. Pull the brake releases backward.
2. Engage Motor Locks
a. At the back of the chair you will find two levers marked in red.
b. Push the brake releases forward. (A).
X. Operating Guide
27
English
A
