3.2 Label explanations
Lever position for the LEFT-HAND freewheel mechanism
Salsa M
2
(& SALSA from August 2010).
Tick = IN DRIVE, Cross = IN FREEWHEEL
Lever position for the RIGHT-HAND freewheel
mechanism Salsa M
2
(& SALSA from August 2010).
Tick = IN DRIVE, Cross = IN FREEWHEEL
WARNING – Do Not Touch - HOT
Attached to Joystick
WARNING – Do not drive your wheelchair on a slope
with the backrest reclined and/or the seat lifted
WARNING – Danger of finger entrapment
WARNING – Maximum user weight for the chair is
140Kg or *160kg for Salsa R
2
with Rehab Seat
The serial number and information label is located on the front
right hand side of the main frame.
Indicates battery charge point
Crash Tested / Tie down points
WARNING – Do Not Touch - Static may damage
equipment
