Section IV - QCS900 & QCS1600
Connecting the Feed Line
The connecting adaptor can be turned in
relation to the inflow direction:
Remove the screws (notice O-ring and
washers of connecting adaptor).
Place connecting adaptor into position.
Replace the screws and tighten.
♦
♦
♦
Connect the inlet hose to any adapter
inlet point using a hose clamp (use the
hose connectors supplied with the unit).
Make sure that the unused inlet points
are tightly plugged.
notiCe
Shut off condensate drain outlet until
the oil/water separator has been
installed and is ready to be put into
service.
♦
♦
20 Quincy Compressor-QCS High Efficiency Emulsion Separators
