2. Never lean or place your body weight on the levers. This will damage the
mechanism.
3. Do not attach shopping, dog leads or anything to the lever. Take care if you use
a weather cover, when removing it don't catch the lever and damage it.
WARNING NOTICE!!
The lever mechanism as shown in the diagram below should be treated with care as it
could become damaged if misused. Do not push or pull both levers in at once. This will
damage the mechanism. Carry out the following recommended checks:-
1. (Carry out daily) Before using the scooter, check the throttle lever mechanism has
full and free movement. With the ignition off (see 1.) and the key removed, push
the lever in fully on the right hand side then release (see 2a). The lever should
return immediately to the normal position (see 2). Push the left hand side lever in,
fully, then release (see 2b). The lever should return immediately to the normal
position. If the lever does not return immediately to the normal position (it sticks)
contact your provider immediately and DO NOT ATTEMPT TO OPERATE THE
SCOOTER. The Handbrake (see 3): This is for emergency use only. (In the
unlikely event that the main braking system should fail this can be used to slow the
This controls the position of the
steering to suit your preference.
Do not adjust when moving.
3. Handbrake-
Emergency use only
Lever shown in normal position
2. Throttle Lever Mechanism
Push in fully and release-First
test the left then the right
Right lever to
go forwards
1. Remove Ignition
Key (Circled)
Checking for Full & Free Movement
Caution: If the ignition switch is turned off while the vehicle is at
speed the vehicle will come to an abrupt stop. If you are in a
situation where you need to stop abruptly use the emergency brake.
Only switch off the ignition as a last resort.
