Class Type Classified according to EN12184 as class B mobility unit
Speed 6kph (4mph)
Length (without basket) 110cm (43.3”)
Length (with basket) 126cm (49.6”)
Width 59cm (23.2”)
Height (ground to top of seat) 101cm (39.8”)
Height (ground to top of tiller) 105cm (41.4”)
Height (transportation/ folded) 51.5cm (20.3”)
Wheelbase 77cm (30.3”)
Seat Width (between armrest) 43-58.5cm (16.9-23”)
Seat Depth Actual 38cm (15”)
Seat Depth to ISO 7176.7 28cm (11”)
Backrest Height 36cm (14.2”)
Seat height (from ground level) 71cm (30”)
Total Unladen Weight 116.5Kg (256lbs)
Weight of each battery 6Kg
Tyre type/ Pressure Pneumatic/ pressure 30psi/ 2.1bar
Motor 250-watt 2-pole
Battery Capacity Quingo 12V 22Ah x 4 off (6 off optional)
Maximum Carrying Capacity 160Kg (25.0st) (352lbs)
Range (standard 4 batteries) 37Km (23miles) see notes regarding range
Range (optional 6 batteries) 54Km (34miles) see notes regarding range
Turning Radius 102cm (40.2”)
Safe climbing angle 6 degrees
Maximum loading angle 30 degrees
Kerb Climbing 7.5cm (3”) *
Docking Station
Overall Weight (must be lifted in sections) 37.9Kg (83.6lbs)
Side Ramp Weight (each side) 12.6Kg (27.8lbs)
Centre Ramp Weight 2.7Kg (6lbs)
Frame Weight (including side support arms) 10Kg (22lbs)
Overall Length (with supports) 135cm (53.2”)
Folded Length 123cm (48.5”)
Overall Width 77cm (30.3”)
Height 19cm (7.5”)
*Measured as a safe maximum kerb height
Note on range: To measure accurately, the range of the vehicle is an estimate based on
the following:
New batteries
Ambient temperature during test @ 60 degrees
A 100Kg/16st/220lb person loaded on the vehicle
Flat ground test with stop/ start (average motor loading)
