73
Step 4-Loosen the lateral
support arms.
a) Release the suction
clamps from both lateral
support arms.
b) Loosen the thumb screws
on each of the support
arms and manoeuvre
them back towards the
frame, and then tighten
the thumb screws. You
may optionally remove
the base plates or leave
them fixed to the car for
next time.
Step 3- Remove the Front Seat Support Arms.
a) Tilt the cars backrests forward.
b) Loosen the thumb screws to release the front seat support arms, remove the locking
pins and detach the arms from the Docking Station frame.
LOCATING PIN
THUMB SCREW
