© Copyright Qvis ®. All documentation rights reserved. 4
1.9 Technical Parameters
Power Supply:
DC12V+10% 50W
Decoder:
Built-in
Manual Speed:
Pan:0.01
o
360
o
/S, Tilt: 0.01
o
120
o
/S (high speed)
Pan:0.01
o
100
o
/S, Tilt:0.01
o
100
o
/S (Vair-speed)
Preset Speed:
360
o
/S (high speed) / 100
o
/S (Mid-speed)
Pan Angle:
360
o
continuous pan rotation
Tilt Angle:
90
o
(Auto Flip)
Number of Preset:
256
Preset Accuracy:
+0.1
o
Alarm
input/output:
1input, 1 output
Auto Scan:
8 auto scan tracks, user-defined left and right boundaries
and scan speed
Auto Cruising:
8 cruising tracks, each cruising tracks has 32 preset
positions,
user-defined dwell time
Pattern Tour:
4 patterns, up to 500 instructions per pattern
Guard Location:
The dome will rotate back to preset position after a period
of vacant time.
Operating
Humidity:
090%
Operating Temp:
-35
o
C +60
o
C
1.10 OSD Menu Operation
Call up OSD menu
Call Preset 95 to enter the main OSD menu; call Preset 96 to close the
OSD menu or Select Exit
