A.3 Jumper Configurations
Figure A-4 shows the header locations used to configure the various BL2000 options via jumpers.
Figure A-4. Location of BL2000 Configurable Positions
JP3
JP6
JP5
JP4
JP2
GND
GND
JP1
Top Side
Bottom Side
R160
R161
TP17
TP15
R118
