53
7. Technical specifications
Power supply
Supply voltage: 230 V ~ / 50 Hz
Nominal power: 70 W
Consumption: Standby: < 0.5 W
Mechanical power
Nominal torque: 10 Nm
Maximum speed: 30 rpm
DECT radio standard
Transmission frequency: 1880 - 1900 MHz
Transmission power: max. 250 mW
Range: ● Indoors up to 40 m
● Outdoors up to 100 m
Operating conditions
Transient operation (KB):
4 minutes
(maximum running time)
Protection class: II
Protection type:
IP20 (only for use in dry
rooms)
Mains connecting cable: 2 x 0.75 mm
2
(H03VVH2-F)
Permissible ambient
temperature:
0 °C to +40 °C
Sound pressure level (LpA): ≤ 70 dB(A)
