RADEMACHER RolloTron DECT - Permissible Roller Shutter Belts

55
7.2 Permissible roller shutter belts
The RolloTron DECT may be damaged if excessive-
ly long belts are used.
Only use belts of the permissible lengths.
Permissible roller shutter belts
RolloTron DECT
Belt width: Belt thickness Maximum belt length
23 mm
1.0 mm 7.6 m
1.3 mm 6.2 m
1.5 mm 5.2 m
Permissible shutter surface area (m
2
)
Roller shutter
type:
Weight/m
2
Permissible
shutter surface area
(m
2
)
Plastic roller
shutters
(4.5 kg/m
2
) Approx. 6 m
2
Aluminium and
wooden roller
shutters
(10.0 kg/m
2
) Approx. 3 m
2
i
The specifications are intended for guidance only
and apply to an ideal installation situation.
