59
Connecting the power cable
Connecting terminals
The colour coding is irrelevant for this connection. Screw the traction relief in place with the screws supplied and
lay the cable in the cable duct.
Securing the power cable with the traction relief
Traction relief
8.2 Electrical connection
WARNING! WARNING!
A damaged connecting cable may cause a short circuit.
The connecting cable may not be pinched when subsequently
screwing on the RolloTron DECT as this could lead to damage.
