Radial PZ-Pre Speci cations
Inputs 1 & 2: ¼" Phone unbalanced
Input impedance: Normal 6.8k Ohm
Piezo 10Meg Ohm
PZB buffers: +10dB boost
Low-cut  lter: 75Hz / 220Hz
Notch  lter range: 56Hz - 330Hz
Notch Q: -8dB / -15dB
Low EQ: Shelving type +/-12dB (75Hz)
High EQ: Shelving type +/-12dB (7.5kHz)
Mid EQ: Semi-parametric
+/-12dB (82Hz - 5.6kHz)
Power Boost: Unity gain to +12dB max.
Effects Loop: ¼" Phone unbalanced
Send 1k Ohm / Return 15k Ohm
Switching: FET Switching
Output (instrument): ¼" Phone unbalanced,
1k Ohm output impedance
Tuner output: ¼" Phone unbalanced,
6.8k Ohm output impedance
Pre-EQ output: XLR, balanced,
600 Ohm, mic-level
Post EQ output: XLR, balanced,
600 Ohm, mic-level
XLR pin-out:
(AES standard)
pin 1 ground
pin 2 hot (+)
pin 3 cold (-)
Power supply: 15VDC, 400mA (included),
center pin positive
Size (W x D x H): 8”x 4.25”x1.37” (203x108x35mm)
Weight: 2.65 lbs. (1.2 kg)
Warranty: 3 Years, transferable
