diono.com
45
FORWARD–FACING
SAFE STOP
Safe Stop is for use ONLY in forward-facing
installations from 22–40 lb (10–18 kg).
DO NOT use rear-facing. DO NOT use in booster mode.
IMPORTANT: The Safe Stop will need to be removed
once the child reaches 40 lb (18 kg).
1. Detach Safe Stop from back
of seat.
2. Remove harness straps from
metal plate. Detach harness
from metal plate on back of
seat. Once detached, thread both
harness straps onto the metal
hook of the Safe Stop. Connect left
side of harness rst, then follow
with the right.
3. 3. Thread bottom of Safe Stop Thread bottom of Safe Stop
onto the harness strap onto the harness strap
hook. hook. Check to ensure proper
engagement to the metal plate.
Take care to ensure harness
straps are not twisted and are
clear from any obstructions.
1
2
1
2
3
