Operation
This chart shows the parts assigned to each
channel.
Notes:
• Normally, keyboard play is assigned to
Channel 1 and the drum pads are
assigned to Channel 10. When you use
auto accompaniment, each part is
assigned to Channels 7–10.
• When you use the keyboard as the
sound source for another MIDI device,
all 16 channels are assigned musical
instrument parts (Channel 10 is
reserved for drum parts only, per MIDI
standard).
• The mixer settings also affect the corre-
sponding MIDI output.
Mixer Modes
Your mixer has two modes; Internal and Ex-
ternal. Internal mode is for keyboard play,
without connecting any external device. Ex-
ternal mode is when you connect another de-
vice through the keyboard’s MIDI ports. The
keyboard stores the settings for internal and
external modes separately.
Editing the Status of a Channel
You can edit the status (On, Off, Solo) of a
channel to delete a specific part or to play a
specific part by itself.
To edit the status of a specific channel, se-
lect the mixer mode by repeatedly pressing
MIXER SELECT
until the desired mode ap-
pears (
INTERNAL
,
EXTERNAL
,
EXTER-
NAL
SOLO,
or
EXTERNAL
PLAY
). Then
press
CHANNEL
.
•
Internal Mode:
Pressing a
CHANNEL
button toggles between on and off
(except CH5, which changes the auto
accompaniment volume).
•
External Mode:
Pressing a
CHANNEL
button toggles between on and off.
•
External Solo Mode:
Pressing a
CHAN-
NEL
button turns that channel on and all
other channels off.
•
External Play Mode:
Pressing a
CHAN-
NEL
button turns that channel off and all
others on.
The channels that are on have thick frames
in the channel number display, while the
Channel Part
1 UPPER1 Main tone
2 UPPER2 Layered/Auto
Harmonize tone
3 LOWER1 Split tone
4 LOWER2 Layered/split tone
(or Auto Harmonize)
5 ACC VOL Accompaniment volume
6 CHORD 1 Auto accompaniment chord
1
7 CHORD2 Auto accompaniment chord
2
8 CHORD3 Auto accompaniment chord
3
9 BASS Auto accompaniment bass
part
10 RHYTHM Auto accompaniment
rhythm
11 TR1 Song Sequence Track 1
12 TR2 Song Sequence Track 2
13 TR3 Song Sequence Track 3
14 TR4 Song Sequence Track 4
15 TR5 Song Sequence Track 5
16 TR6 Song Sequence Track 6
