Congratulations
for
selecting
this
Radio Shack computer product!
The
Quick
Printer II is a
compact,
affordable
and extremely
versatile
line printer. You can
connect
it directly to
the TRS-80,
to
the
Expansion Interface via
an optional cable, or
to
a serial
(RS-232C)
output
unit.
A
built-in
microprocessor controls the Printer
and
communicates with the output device (TRS-80
or other Computer,
etc.).
Other
exceptional
features include:
•
Upper and
lower case characters
•
Software
selectable 16 and 32 characters/line
printout
•
Switch-selectable inputs: TRS-80,
TRS-80 Expansion
Interface,
or Serial
Interface
•
ON-LINE/BUSY/RESET
Switch
•
Automatic "wrap-around" when
text exceeds maximum
line
length
—
no
lost data
due to overflow
Note: The Quick
Printer
II
is supplied with a cable
for connection
to
the TRS-80.
For connection to the TRS-80 Expansion
Interface,
you
need to
buy
an
optional extra cable,
Catalog Number
26-1406.
Contents
Controls
and Functions
3
Paper
Loading
Instructions
4
Connection
6
Power-Up Messages 9
Using the
PRINT
Mode Switch 10
Output to
the Quick Printer II
11
Special Features
11
Details of Operation
13
Assembly
Language Output
15
Using with a Serial
Output
Device
17
If
You Have Problems
19
Care and Maintenance
.".
20
Specifications
21
Schematic
Diagram
22
