Radio Shack XL-200 - Two-Speaker Connection Methods

10
Connecting Inputs
Two Speaker Outputs
Floating Ground Connection
Common Ground Connection
White/
Black
Gray/
Black
White
Gray
Right +
Left + Left – Right –
Auto Sound System
White/
Black
Gray/
Black
White
Gray
Right +
Left +
Auto Sound System
Common
