05
Installing and removing the belt clip
1. Align the two holes of belt clip and the two holes of the radio, fix them with the supplied
M2.5 X 5 screw.
2. Loosen the screw set to remove the belt clip
Installing external headset
Reveal (do not remove) the mic/speaker jack cover, insert the headset into the mic/speaker jack.
06
