16
RECEIVER
Sensitivity
1/2-watt of audio output
greater than 1/2watt of audio output
watt of audio output
Adjacent-Channel Selectivity AM/FM: 60dB SSB: 70dB
Image Rejection More than 65dB
IF Frequency
AM/FM: 10.695MHz 1st IF, 455KHz 2nd IF
SSB: 10.695MHz
RF Gain Control 45dB adjustable for optimum signal reception
Automatic Gain Control(AGC)
Less than 10dB change in audio output for inputs
from 10 to 100,000 microvolt.
Squelch
Audio Output Power 3 watts into 8 ohms
Frequency Response AM/FM: 300 to 3000Hz SSB: 450 to 2500Hz
Built-in Speaker 8 ohms, round.
External Speaker(Not Supplied)
8 ohms; disables internal speaker when
connected.
WX channels
WX-01 162.400MHz
WX-02 162.475MHz
WX-03 162.425MHz
WX-04 162.450MHz
WX-05 162.500MHz
WX-06 162.525MHz
WX-07 162.550MHz
