Radioddity QT60 User Manual

3
ANTENNA INSTALLATION
POWER CONNECTION
Before using this radio, please install a high efficent and harmonious adjusted
CB antenna, suitable antenna type and correct installation will bring excellent
communication.
To match with the radio, the antenna and cable shall with characteristic impedance of
electronics.
1. Screw the antenna connector into the antenna jack.
2. Grounding the antenna system to ensure best performance of this radio.
This radio adopt 13.8V power supply, never connect it to 24V battery, And the 13.8V car
will drop down.
3. The position of antenna can be put as following example:
1. Connect positive red power cable with the + terminal of the battery.
2. Connect negative black power cable with the - terminal of the battery.
3. Connect the DC power cable to the transceiver's power supply connector.
insulator.
from the cable.
Connected
to chassis
WARNING:
equip of lightning protector
