Radioddity QT60 User Manual

15
TRANSMITTER
Power Output AM PEP: 60W / FM: 50W / SSB: 60W(PEP)
Drain 10A(with modulation)
Modulation AM/FM/USB/LSB
Inter-modulation Distortion
SSB: 3rd order, more than -25dB; 5th order,
more than -35dB
SSB Carrier Suppression 55dB
Unwanted Sideband 50dB
Frequency Response
AM/FM: 300 to 3000Hz
SSB: 450 to 2500Hz
Output Impedance 50ohms, unbalanced
SPECIFICATIONS
GENERAL
Frequency Range 28.000-29.700MHz(Programmable)
Frequency Band A/B/C/D/E/F/G/H/I
Channel
40 channels in each band (a total of 60
programmable channels)
Frequency Control Phase-Locked-Loop Synthesizer
Frequency Step 100Hz,1KHz,5KHz,10KHz,100KHz,1MHz
Frequency Tolerance ±5.00ppm
Temperature Range -20
to +50
Microphone with push-to-talk /UP/DN and coiled cord
Input Voltage 13.8V
Dimensions (in mm) 305(L)x200(W)x60(H)
Weight 1.73kg
Antenna Connector UHF, SO239
