RadioLink T7F-2.4Ghz User Manual

Receiver
Output
Channel
Aircraft(ACRO) Helicopter(HELI)
1
Aileron
2
Elevator-or-left ruddervator(for V-Tail models)
–or-left elevon( for tailless models)
Elevator
3 Throttle Throttle
4 Rudder-or-right ruddervator(for V-Tail models) Rudder
5 Retractable landing gear Gyro sensitivity
6 Flap-or-left flapron Pitch
7 Auxiliary Auxiliary
A ileron Servo
(CH1)
Optional
Gyro
System
Elevator Servo
(CH2)
Throttle Servo
(CH3)
Rudder Servo
Rudder (CH4)
P itch Servo
(CH6)
Gyro Sensitivity (CH5)
Gear Servo
(CH5)
Flap Servo
(CH6)
AUX
(CH7)
Elevator Ser
A ileron Servo
vo
(CH2)
(CH1)
Throttle Servo
(CH3)
Rudder Servo
(CH4)
(CH1)
(CH6)
(CH1)
(CH2)
(CH4)
(CH2)
(CH4)
Flaperon Mode (Dual Aileron
Servo, CH1 & 6)
Independent Aileron & Flap
(CH6)
R7EH
7Channel Receiver
ID SET
FHSS
1
2
3
4
5
6
7
R7EH
7Channel Receiver
ID SET
FHSS
1
2
3
4
5
6
7
AUX
(CH7)
8

RadioLink T7F-2.4Ghz Specifications

General

Brand	RadioLink
Model	T7F-2.4Ghz
Category	Remote Control
Language	English
