Type：Curve type
Standard type, only Y point (output) can be edited, ranging from -100 to 100
Custom types, both X (input) and Y (output) points are editable, ranging from -
100 to 100
Count：The number of points on the curve, between 2 and 17.
Smooth：If checked, create a smooth curve through all points.
When customizing, move the cursor to X and Y coordinates, and change the position of
each coordinate point according to your needs.
Depending on the type selected above, this allows writing the X coordinate of a standard
curve, or the X and Y coordinates of a custom curve.
Long press the ENT key on the coordinate point to enter the submenu：
Preset：Select presets with slopes of -45 °, -33 °, -22 °, -11 °, 0 °, 11 °, 22 °, 33 °, 45 °.
When defining more complex curves, choose reasonable presets Will reduce some steps.
Mirror：Mirror the curve vertically.
Clear：Clear the current curve.
3.4.8. Logic switches（Logical Switches）
The logic switch is a user-programmed virtual switch. Like the physical switch, the logic switch is
also a switch, but unlike a physical switch, which can be moved by hand, the logic switch is an
internal switch triggered by certain user-programmed conditions. The judgment condition you
set allows the radio control to automatically turn on or off the logic switch to achieve a certain
or a series of automated actions.
