Specifications
Primary Power Supply
• 16.5 VAC, 40 VA class 2 plug-in transformer (D1640)
Secondary Power Supply
• 12 VDC, 7.0 Ah sealed lead acid rechargeable battery.
Auxiliary Power Output
• 1 A maximum at 10.2 VDC to 13.9 VDC for devices powered at
terminal 9 (140mA for Fire and combined Fire/Burglary systems).
Alarm Power Output
• 1.85 A maximum at 10.2 VDC to 13.9 VDC output. Output may
be steady or pulsed depending on programming.
• Fire and Fire/Burglary Systems
To comply with UL 985 listing standards for household fire alarm
systems, the total combined continuous and alarm current draw
for the system during alarm conditions must be limited to 860
mA provided by the primary power supply (rectified AC).
Operating Voltage
• 10.2 VDC (minimum) 13.9VDC (maximum)
Telephone Connection
• RJ31X or RJ38X jack interfaced with D164 phone cord.
Environmental
• Temperature: 32°-122°F (0°-50°C)
• Relative Humidity: 5-85% at 86°F (30°C) non-condensing
D2203 Enclosure Dimensions
Height: 14.75 inches, Width: 12.75 inches, Depth: 3.5 inches
Arming Stations
• D202A Keypad, D220A Keypad, D222 Keypad,D223 Keypad
• D204RF Keypad
• Keyswitch
• Easikey
Compatible Enclosures
• D2203 or D8103 Universal Enclosures
• D8109 Fire Enclosure
• D8108A Attack Resistant Enclosure
Compatible Accessories (see Radionics catalog for complete list)
• D126 12V, 7 Ah Rechargeable Battery
• D127 Reversing Relay
• D132 Smoke Detector Reversing Relay Module
• D133 Relay Module
• D134 Dual Relay Module
• D135A Low Battery Cutoff Module (not UL listed)
• D164 Phone Cord
• D192C Bell Supervision Module
• D202A Keypad
• D204RF Keypad (not UL listed)
• D208 8-Point Expansion Module
• D220A Keypad
• D222 Keypad
• D223 Keypad
• D250 Heat Detector Base
• D254 135° Heat Detector Head
• D255 190° Heat Detector Head
• D440 (6"), D442 (10") Bells
• D448 12 VDC Horn
• D1640 16.5 VAC 40 VA Transformer
• D5200 Programmer
• D5300 Remote Account Manager II
• D8004 Transformer Enclosure
• D8121A/D8122 Derived Channel S.T.U. (D8122 for UL systems)
• Easikey (not for use in UL systems)
• D261A Smoke Detector Base
• D262 Smoke Detector Head
• D208 RF Receiver
• D216 RF Receiver
Radionics, Inc., 1800 Abbott Street Radionics, 1 Park Gate Close, Bredbury
Salinas, California 93901 Stockport, Cheshire, SK6 2SZ, England
Customer Service: (800) 538-5807 Technical Support: (061) 494 0851
™The Radionics logo is a registered trademark of Radionics, Inc., Salinas, CA, U.S.A. ©1995 Radionics, Inc., Salinas, CA, U.S.A. All rights reserved
D2212 Terminal Quick Reference
Terminal Description
1,2 AC Input Connect 16.5 VAC, 40 VA transformer for
prim ary power source.
3 Earth Ground Connect to ear th ground. A cold water
pipe or gr ounding rod is preferred.
Do not connect to telephone or electrical
ground.
4 Battery
Positive
Connect Positive terminal of 7.0 Ah
battery to this terminal.
5
Battery
Negative
Connect Negative terminal of 7.0 Ah
battery to this terminal
6 Alarm Output
Positive
Supplies 1.85 Amps at 10.2 to 13.9 VDC
for alarm output.
This terminal provides a constant output.
Negative is switched.
7 Alarm Output
Negative
Negative terminal for alarm output. This
ter minal switches for pulsed or steady
alarm output.
8 Data Data for Keypads, RF Receiver s, etc.
9 Auxiliary Power
Positive
One Amp at 10.2 to 13.9 VDC for
auxiliary power, keypads, and relay
outputs.
10 Common Common for Auxiliary Power and Relay
Drivers.
11 External
Relay 1
Connect D133/D134 Relay for Form C
Dry Contact.
12 External
Relay 2
Connect D133/D134 Relay for Form C
Dry Contact.
13 Positive
Point 1
Positive power for Point 1. Switched for
sensor reset.
Use approved 2-wire smoke or glass
break detector s.
14 Negative
Point 1
Negative power for Point 1.
15 Comm on Comm on for Point 2.
16 Input Point 2 Input for Point 2.
17 Input Point 3 Input for Point 3.
18 Comm on Comm on for Points 3 and 4.
19 Input Point 4 Input for Point 4.
20 Input Point 5 Input for Point 5.
21 Comm on Comm on for Points 5 and 6.
22 Input Point 6 Input for Point 6.
23 Input Point 7 Input for Point 7 (no EOL resistor).
24 Comm on Comm on for Points 7 and 8.
25 Input Point 8 Input for Point 8. No EOL Resistor .
26 T1 Tip of phone line to pr emises phone.
27 T Tip of incoming phone line.
28 R Ring of incoming phone line.
29 R1 Ring of phone line to premises phone.
