INSTALLING THE MISB DATA AND
POWER CABLE
The ESP-LX PLUS cabinet has five knockouts for routing
field wires. Three are located on the underside of the cab-
inet and two are located on the back
• The underside of the cabinet has a knockout for a PVC
male adapter sized
3
⁄4" (1,9 cm) on the right hand side
of the controller. This is the hole to be used for routing
of the MISB Data and Power Cables from the LX-Plus
Controller. Conduit is recommended between the two
cabinets.
• Run the MISB data (end without the ferrite bead) and
power cables between the two cabinets. There should
be 36” (91.4 cm) of cable available, external to the two
cabinets. Recommended conduit run is 6” (15,2 cm)
vertical under each cabinet. Horizontal distance is
based on cabinet mounting - recommended minimum
distance between cabinets is 9
1
⁄2” (24,1 cm).
In the MISB Cabinet:
• The bottom (center) of the MISB Cabinet has a knock-
out for a PVC male adapter sized 1” (2,5 cm) surround-
ed by a knockout for a 1
1
⁄4” (3,2 cm) adapter. The 1”
(2,5 cm) knockout is what is to be used for routing the
MISB data and power cables into the MISB Cabinet. If
using conduit, you will need a
1
⁄2” (1,9 cm) to 1” (2,5
cm) conduit adapter to upsize the conduit to fit the
knockout. Note: the right-hand
3
⁄4" (1,9 cm) knockout
will be used for sensor and phone cables.
• Plug the three-wire (black, white, and green) power
cable into the J4 connector on the bottom edge of the
MISB, to the left of the sensor ports. Note: If you have a
240 VAC, 50 Hz controller your power cable will only
have two-wires (black and white).
• Connect the six-wire cable to the J1 connector on the
MISB.
ESP-LX Plus Site Satellite Controller Addendum8
