RainHarvest Systems Standard Output System Specicaons
RAINHARVEST SYSTEMS EQUIPMENT SPECIFICATIONS
Mul-Use / Residenal systems (standard output lamps)
MODEL
RF4-2
RF5-2
RF6-2
RF4-3
RF5-3
RF6-3
RF4-6
RF5-6
RF6-6
RF4-11
RF5-11
RF6-11
RF4-15
RF5-15
RF6-15
RF4-21
RF5-21
RF6-21
Flow Rate
16mJ/cm
2
@ 95% UVT
3.8 gpm 6.1 gpm 11 gpm 20 gpm 30 gpm 39 gpm
15 lpm 23 lpm 41 lpm 77 lpm 110 lpm 150 lpm
0.87 m
3
/hr 1.4 m
3
/hr 2.5 m
3
/hr 4.6 m
3
/hr 6.8 m
3
/hr 8.9 m
3
/hr
Flow Rate
30mJ/cm
2
@ 95% UVT
2.0 gpm 3 gpm 6 gpm 11 gpm 15 gpm 21 gpm
7.6 lpm 11.4 lpm 22.7 lpm 41 lpm 57 lpm 79 lpm
0.45 m
3
/hr 0.70 m
3
/hr 1.4 m
3
/hr 2.5 m
3
/hr 3.4 m
3
/hr 4.8 m
3
/hr
Flow Rate
40mJ/cm
2
@ 95% UVT
1.6 gpm 2.4 gpm 4.4 gpm 8.3 gpm 12 gpm 16 gpm
6.1 lpm 9.1 lpm 17 lpm 31 lpm 45 lpm 59 lpm
0.36 m
3
/hr 0.50 m
3
/hr 1.0 m
3
/hr 1.9 m
3
/hr 2.7 m
3
/hr 3.6 m
3
/hr
Port Size ½”FNPT ½”MNPT ¾”MNPT ¾”MNPT 1”MNPT 1”MNPT
Electrical 90-265V/50-60Hz. 1A Max.
Plug Type American: NEMA 5-15P
Lamp Power (Was) 8 15 22 39 50 42
Power (Was) 14 20 30 49 62 51
Replacement Lamp RF-L210 RF-L290 RF-L470 RF-L820 RF-L999 RF-L850
Replacement Sleeve RF-Q210 RF-Q290 RF-Q470 RF-Q820 RF-Q999 RF-Q850
Reactor
Dimensions
6.4 x 26.2 cm
(2.5 x 10.3”)
6.4 x 36.4 cm
(2.5 x 14.3”)
6.4 x 54.2 cm
(2.5 x 21.3”)
6.4 x 89.5 cm
(2.5 x 35.2”)
6.4 x 101.6 cm
(2.5 x 40.0”)
8.9 x 91.7 cm
(3.5 x 36.1”)
Chamber
Material
304 Stainless Steel, A249 Pressure Rated Tubing
Controller
Dimensions
17.2 x 9.2 x 10.2 cm (6.8 x 3.6 x 4”)
Operang
Pressure
0.7-10.3 bar (10-150 psi)
Operang Water
Temperature
2-40° C (36-104° F)
UV Monitor YES on all “RF6” models. Upgrade available for “RF5” models (NOT available on RF4 models)
Solenoid Output YES (oponal solenoid module (MOD-SOL1-RF) sold separately)
Dry Contacts YES (remote alarm module (MOD-RAM-RF) sold separately)
4-20mA Output YES (4-20mA module (MOD-420-RF) sold separately)
Temperature Mgmt. Valve NA
PN# RF-
TRV-0.5
PN# RF-TRV-0.75 PN# RF-TRV-1
Cooling Fan NO
OPTIONAL
(MOD-FAN-RF)
Lamp Change Reminder YES
Lamp Out Indicator YES
Shipping Weight
2.9 kg
(6.3 lbs)
3.6 kg
(7.9 lbs)
4.4 kg
(9.6 lbs)
6.0 kg
(13.2 lbs)
6.5 kg
(14.4 lbs)
8.2 kg
(18.0 lbs)
