RAINHARVEST SYSTEMS EQUIPMENT SPECIFICATIONS
Residenal Crossover systems (high output lamps)
MODEL
RF4-5C
RF5-5C
RF6-5C
RF4-10C
RF5-10C
RF6-10C
RF4-15C
RF5-15C
RF6-15C
RF4-25C
RF5-25C
RF6-25C
RF4-40C
RF5-40C
RF6-40C
Flow Rate
30mJ/cm
2
@ 95% UVT
5.0 gpm 10 gpm 15 gpm 25 gpm 40 gpm
18.91 lpm 37.9 lpm 57 lpm 95 lpm 151 lpm
1.1 m
3
/hr 2.3 m
3
/hr 3.4 m
3
/hr 5.7m
3
/hr 9.3m
3
/hr
Flow Rate
40mJ/cm
2
@ 95% UVT
3.0 gpm 7.0 gpm 11 gpm 19 gpm 31 gpm
11 lpm 26 lpm 42 lpm 72 lpm 120 lpm
0.68 m
3
/hr 1.6 m
3
/hr 2.5 m
3
/hr 4.3 m
3
/hr 7.0 m
3
/hr
Flow Rate
Hot Water (-HW sux) model
30mJ/cm
2
@ 75% UVT
2.8 gpm 7.0 gpm 9.8 gpm 16 gpm 28 gpm
11 lpm 26 lpm 37 lpm 61 lpm 110 lpm
0.6 m
3
/hr 1.6 m
3
/hr 2.2 m
3
/hr 3.6 m
3
/hr 6.4 m
3
/hr
Flow Rate
Low UVT (-50 sux) model
30mJ/cm
2
@ 50% UVT
1.7 gpm 4.2 gpm 6.1 gpm 10 gpm 17 gpm
6.4 lpm 16 lpm 23 lpm 38 lpm 64 lpm
0.4 m
3
/hr 1.0 m
3
/hr 1.4 m
3
/hr 2.3 m
3
/hr 3.9 m
3
/hr
Flow Rate
TOC (-TOC sux) model
150mJ/cm
2
@ 98% UVT
0.8 gpm 2.0 gpm 2.8 gpm 5.1 gpm 8.0 gpm
3.0 lpm 7.6 lpm 11 lpm 19 lpm 30 lpm
0.2 m
3
/hr 0.5 m
3
/hr 0.6 m
3
/hr 1.1 m
3
/hr 1.8 m
3
/hr
Port Size ¾”MNPT ¾”MNPT 1”MNPT 1”MNPT 1 ½”MNPT
Electrical 90-265V/50-60Hz. 1.5A Max.
Plug Type American: NEMA 5-15P
Lamp Power (Was) 18 34 45 67 101
Power (Was) 20 36 48 72 108
Replacement Lamp RF-L210C RF-L330C RF-L420C RF-L600C RF-L950C
Replacement Sleeve RF-Q210 RF-Q330 RF-Q420 RF-Q600 RF-Q950
Reactor
Dimensions
8.9 x 29.8 cm
(3.5 x 11.7”)
8.9 x 41.8 cm
(3.5 x 16.5”)
8.9 x 50.8 cm
(3.5 x 20.0”)
8.9 x 68.3 cm
(3.5 x 26.9”)
8.9 x 103.4 cm
(3.5 x 40.7”)
Chamber Material 316L Stainless Steel, A249 Pressure Rated Tubing
Controller Dimensions 21.7 x 10.8 x 10.2 cm (8.6 x 4.2 x 4”)
Operang Pressure 0.7-10.3 bar (10-150 psi)
Operang Water Temperature 2-40° C (36-104° F)
UV Monitor YES on all RF6 models. Upgrade available for RF5 models (NOT available on RF4 models)
Solenoid Output YES (oponal solenoid module (MOD-SOL1-RF) sold separately)
Dry Contacts YES (remote alarm module (MOD-RAM-RF) sold separately)
4-20mA Output YES (4-20mA module (MOD-420-RF) sold separately)
Temperature Mgmt. Valve PN# RF-TRV-0.75 PN# RF-TRV-1 PN# RF-TRV-1.5
Cooling Fan OPTIONAL (MOD-FAN-RF sold separately)
Lamp Change Reminder YES
Lamp Out Indicator YES
Shipping Weight
4.4 kg
(9.7 lbs)
5.2 kg
(11.5 lbs)
5.6 kg
(12.9 lbs)
7.0 kg
(15.5 lbs)
9.6 kg
(21.1 lbs)
