Assembly
Unpack the system and ensure all the components are included with the system. Your system is
shipped with the following components:
RainHarvest Systems (Standard output lamp systems)
CONTROLLER
GLOW PLUG
(RF5 units only)
UV SENSOR
(RF6 units only)
4.1 SYSTEMS
RF4
5.1/6.1 SYSTEMS
RF56
300016 Complete Assembly
310026 Teon Plug
310040 O-Ring
390007 Brass Nut
RF-S1 RF4/RF5/RF6-06,
-10, -15 series
RF-S2 RF4-20, RF5-20,
RF6-20 series
GLAND NUT
O-RING
SLEEVE SPRING
QUARTZ SLEEVE
REACTOR
UV LAMP
320006
310038
RF-L210 “-02” series
RF-L290 “-03” series
RF-L470 “-06” series
RF-L820 “-10” series
RF-L850 “-20” series
RF-L999 “-15” series
310039
RF-Q210 “-02” series
RF-Q290 “-03” series
RF-Q470 “-06” series
RF-Q820 “-10” series
RF-Q850 “-20” series
RF-Q999 “-15” series
300083 “-02” series
300050 “-03” series
300052 “-06” series
300054 “-10” series
300061 “-15” series
300068 “-20” series
LAMP KEY
