RainPro HDC-4 - Icons on the THC Display

19
valve solenoid.
Icons on the THC Display
Icon Description
1. % Indicates Seasonal Adjust
2. AM Indicates time of day AM or PM
3. PM
4. TIME Displayed to set current time
5.MONTH Displayed to set current month
6.YEAR Displayed to set current year
7.RUN Displayed to indicate program is
running
