PROGRAMMING THE CONTROLLER
To successfully program controller, all three
programming elements must be completed. They
are:
Program Start Times (Time of day a complete
programmed irrigation cycle will start).
Station Run Times (The length of time each
station/valve will irrigate).
Calendar/Schedule (The days of week/calendar
that you desire to irrigate).
To program the controller, you are provided + or –
buttons that will change the value of the “flashing
display”. The ? or ? change the subject of
information that is flashing. The subject or
“Flashing display” is in sequence and can be
scrolled forward ? or backward ? to access all
desired programming options.
BASIC PROGRAMMING FEATURES
1) Three independent programs are
available “A”, “B” and “C”.
2) Three program start times are available
per program.
