Raise3D PRO2 Series - H. Dual-Extruder Print - Start First Print; Step 10: Adjust Z-Plate Screw for Leveling; Step 12: Select and Print Dual Extrusion File

Pro2-Series 3D Printer / Quick Start Guide
11
USB Storage
Insert the USB storage that contains your sliced
model (.gcode and .data files).
Insert this USB drive into the USB slot on the side of
touchscreen.
Open the “Print” tab, and choose “USB Storage” to
open the file storage path. Select your dual extrusion
file to check the printing parameters and settings.
Press “Print” to start printing test file.
12
H. Dual-Extruder Print - Start First Print (continued)
The distance between the nozzle and the printing
platform can be adjusted by turning the thumb
screw on the left-front corner of the
Z-plate, the higher the screw stands, the further the
distance between the nozzle will be from the printing
platform.
Home the Z axis after each adjustment.
10
