RAM CRYSTAL User Manual

SECTION 3 - MOTORS AND RUNNING GEAR
Page 3-3
Rev 1B – May 2013
3.4
Install motor. (FIG. 4).
3.5
Move the working platform to the top of the second cross
brace to begin installation of the counter weights.
Figure 4. Motor installation. Looking from in front of
the guide rails.
MATERIAL LIST PART #
1. AC motor
2. Gearbox
